3D Printer Part 2P 3P 4Pin 15EDGKP 3.81MM Plug-in Type PCB Connection Terminal Block Male Female Connector For 28 to 16 AWG Cable
Model : 15EDGP+K
Spacing: 3.81mm
Rated Voltage : 300V
Number of digits: 2P-4P
Rated Current: 8A
Plastic Parts: PA66 Flame Retardant Nylon
Use Wire Diameter: 0.2-1.5mm
Square Buckle: Nickel-plated Brass
Stripping Length: 7-8mm
Contacts: Nickel-Plated Copper/Tin-Plated Copper
Ambient Temperature: -40℃~+105 ℃
Screw: M2.0 Steel Galvanized
Include : 2pcs/set (male + female)
2ชิ้น/ชุด (ตัวผู้ + ตัวเมีย)
